CCS 2 DC charging cable

300A 250A 200A 150A 125A 80A

DC charging cable, with vehicle charging connector and open cable end, for charging electric vehicles (EV) with direct current (DC), supports four-conductor measurement technology, with analog temperature sensors, with replaceable mating face frame, with replaceable DC power contacts, with connected PP contact, CCS type 2, based on IEC 62196-3, MAX 300 A / 1000 V (DC), Customized logo, cable: Customized logo, black, straight.

Chat Now

Features

Meet 62196-3 IEC standards
Concise appearance, support back installation
Contact with drainage structure, improve safety performance
Safety pins insulated head design to prevent accidental direct contact with staff
Back protection class IP55
DC max charging power 300kW

Electric Performance

DC input: 80A / 125A / 150A / 200A / 250A / 300A 1000V DC MAX
DC Max charging power: 300KW
Insulation resistance: >5000MΩ (DC1000V)
Terminal temperature rise.: <50K
Withstand Voltage: 3000V
Contact Resistance: 0.5m Ω Max

Mechanical Properties

Mechanical life: no-load plug in / plug out > 10000 times
Coupled insertion force: >45N<80N
Impact of external force: can afford 1m drop test and 2T vehicle run overpressure
Case Material: Thermoplastic, Flame retardant grade UL94-0
Contact bush: Cooper alloy+ thermoplastic on the top

Environmental performance

Operating temperature:-30°C – +50°C
