2Pins Metal HV Connector
65A MAX
High Volatge 2Pins metal connector system can achieve 65A at up to 1000V. Shell made by metal, anti-corrosion plated, with high mechanical strength,light weight, small shape, 360° shielding and more security in using.
With secondary locking function to prevent accidental disconnection caused by incorrect operation.
This product has been granted a patent for a 360 ° rotatable plug-in energy storage connector.
Applications
Products used for EV high-volatge connection between Air conditioning, PTC, Electric defrosting, etc.
Electric Performance
- Rated volatge : 1000V
- Withstanding voltage : 3500V
- Rated current : 65A MAX (85℃)
- Insulation resistance : 5000MΩ
Mechanical Properties
- Pole: 2pole
- Mating cycles : ≥250 times
- Cross sections : 2.5mm² 4mm2 6mm2
- Vibration class acc. to : QC/T 1067.1-2017 V3
Environmental performance
- Operating temperature : -40℃~125℃
- Protection Degree : IP67
- Salt Spray : 96h
